AUTOFOR，the innovator of "precision cutting technology"!
--Even if you produce a pot,you should let it service for several genaration!
| Place of Origin: | China |
|---|---|
| Brand Name: | AUTOFOR |
| Certification: | CE/SGS/ISO90001 |
| Model Number: | CX355 |
| Minimum Order Quantity: | 100pcs |
| Price: | Negotiable |
| Packaging Details: | carton/wooden/customized |
| Delivery Time: | 15 days |
| Payment Terms: | L/C, T/T, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 1000000 pcs/m |
| Material: | Resin | Product Name: | Cutting Disc |
|---|---|---|---|
| Accuracy: | ±0.05mm | Application: | Amorphous, Nanocrystalline, Ultrafine Crystalline, Silicon Steel, Silicon Steel, Beryllium Film, Transformer, Ferrite, Ferrosilicon, Ferronickel , Ferrosilicon-aluminium |
| Size: | 355*1.2*31.7cm/customized | Max Speed: | 4700 R/min |
| Highlight: | ultra thin cutting discs,metal cut off wheel |
||
Precision Cutting Wheel For Ferrite Core And Other Shapes
If you need cut ferrite core of the other shapes of ferrite,and if you face any problem of cutting magnetic cores,please kindly contact AUTOFOR to solve the problems.We have the R&D team to solve the problems of cutting system.
W e can designed for ultra-thin cutting blades for you.
Cutting effects:
AUTOFOR specially develops more than 30 series of precise cut-off Wheel for magnetic cores cutting and gapping,like amorphous, nanocrystalline, ultrafine crystalline,silicon steel, permalloy, beryllium film, transformer, ferrite, ferrosilicon, ferronickel, ferrosilicon-aluminium, which are suitable for different customers and products with different personalized needs. If AUTOFOR cutting wheel matching with AUTOFOR cutting machine,you can achieve cutting port "mirror "effect , even if you don't use secondary grinding, then greatly save labor costs.
Advantages:
1. No burr after cutting ,cutting resistance 20-80% better than Euro-Japanese-American Brand Cutting wheel.
2. No smoke during cutting
3. Cutting port quality very smooth,no burn,no loose
4. Germany technique, original manufacturer,so quality is high and the cost is low.The customers who start to work with us then cooparete for long time.
5. The accuracy is less than ±0.05mm
Magnetic Core Cut-off Wheel specifications (mm)
| Model | OD | THK | ID | Line speed(m/s) |
| CX150 | 150 | ≥0.3 | 12.7/16/25.4/30/31.75/32/40/50 | 50--80 |
| CX180 | 180 | ≥0.3 | 12.7/16/25.4/30/31.75/32/40/50 | 50--80 |
| CX205 | 205 | ≥0.4 | 12.7/16/25.4/30/31.75/32/40/50 | 50--70 |
| CX230 | 230 | ≥0.4 | 12.7/16/25.4/30/31.75/32/40/50 | 50--70 |
| CX255 | 255 | ≥0.5 | 12.7/16/25.4/30/31.75/32/40/50 | 50--70 |
| CX305 | 305 | ≥1.0 | 12.7/16/25.4/30/31.75/32/40/50 | 50--60 |
| CX355 | 355 | ≥1.2 | 12.7/16/25.4/30/31.75/32/40/50 | 50--60 |
| CX405 | 405 | ≥1.5 | 12.7/16/25.4/30/31.75/32/40/50 | 50--60 |
| CX455 | 455 | ≥1.5 | 12.7/16/25.4/30/31.75/32/40/50 | 40--50 |
| CX510 | 510 | ≥2.0 | 12.7/16/25.4/30/31.75/32/40/50 | 40--50 |
Environmental Protection
AUTOFOR is committed to providing high quality and environmental friendly products for customers. We always put the ISO14001 environmental system into practice. All products of its brands have passed SGS environmental certification. The products are harmless to the environment and human body, and they can achieve zero pollution and zero emission. Let us protect the environment and build a beautiful home together by starting with AUTOFOR!
Application field
AUTOFOR products are widely used in aerospace, automobile, energy, electronics, education and other fields. In the industry of precision cutting technology, it has been in the forefront of domestic counterparts.
